1x12,288線陣相位型液晶調制器

高光學效率

光束偏轉

無機械移動

衍射光學

安全的低電壓操作

光譜調諧與處理

高速相位控制

超快脈沖整形

全用戶編程

可編程相位光柵

靈活的系統配置

可編程振幅光柵

安靜低振動操作

全固態器件結構

即插即用簡易安裝

友好的圖形界面

Array Size

19.66x19.66mm

Design Wavelength (nominal)

635-1550nm

(Specify wavelength, λ in nm when ordering)

Diffraction Efficiency (zero-order)

80 - 95% (maximum)

Duty Cycle

Up to 100%

External Window

Broadband antireflection coated for Ravg<1% (over 450-865nm or 850-1650nm)

Fill Factor

100%

Format

1x12,288

Mode

Reflective

Steering Angle

± 4 - 7°

Modulation

Controllable index of refraction

Phase Levels (resolvable)

50 -100 linear levels (minimum) for 2π phase stroke

Phase Stroke (double-pass)

Typically 2π at user-specified laser line

Pixel Pitch

1.6 μm

Reflected Wavefront Distortion (rms)

λ/10 – λ

Response Time

5 - 30 ms

Spatial Resolution

TBD

Switching Frequency

30 – 200 Hz
